Demystifying AWS CloudFormation: Crafting an Amazon EKS Infrastructure

Mahira Technology Private LimitedMahira Technology Private Limited
5 min read

Introduction :-

The provided AWS CloudFormation template is a powerful tool for automating the deployment of an Amazon Elastic Kubernetes Service (EKS) cluster within the AWS cloud environment. EKS is a managed Kubernetes service that simplifies the process of running containerized applications at scale. This template streamlines the creation of the EKS cluster, along with essential IAM roles, security groups, and networking resources, allowing for secure and efficient Kubernetes deployments.

Here’s a breakdown of the key components and resources in your CloudFormation template:

  1. Parameters: These are inputs to your CloudFormation stack, allowing users to customize the deployment. Parameters include the environment name, EKS cluster name, network stack name, EFS port, GRPC port, and availability zone name.

2. Resources: These are the AWS resources that will be created and managed by your CloudFormation stack. Key resources include IAM roles for the EKS cluster and pods, security groups for EKS and EFS, the EKS cluster itself, and an EKS profile.

3. Outputs: These are values or references to resources that you want to make available to other CloudFormation stacks or services. In this case, you’re exporting the EKS OIDC connection URL and the EKS Pod Security Group.

4. IAM Roles: You’re creating two IAM roles, one for the EKS cluster itself (EKSIAMRole) and one for the pods (EKSpodexecutionRole). These roles define what actions the EKS cluster and pods can perform within AWS.

5. Security Groups: You’ve defined security groups for cluster communication with worker nodes (ControlPlaneSecurityGroup), security for Temporal Pods (PodSecurityGroup), and security for the Elastic File System (EFS) (EFSSecurityGroup). These security groups control inbound and outbound traffic for the associated resources.

6. EKS Cluster: The EKS cluster (EKSCluster) is created with the specified configuration, including the cluster name, IAM role, VPC configuration, and Kubernetes version.

7. EKS Profile: An EKS profile (EKSProfiles) is created, which associates the EKS cluster with a pod execution role, namespaces, and subnets. This profile defines which pods can run on the EKS cluster.

8. EFS Security Group: A security group (EFSSecurityGroup) for the Elastic File System (EFS) is defined, allowing inbound traffic from specific subnets.

9. Outputs: You’re exporting the EKS cluster endpoint URL and the EKS Pod Security Group so that they can be used in other CloudFormation stacks or services.

Overall, this template is designed to create and configure an EKS cluster with the necessary IAM roles, security groups, and networking settings to run Kubernetes workloads securely. Make sure to provide the required parameter values when launching this CloudFormation stack, and it should create the specified resources as per your configuration.

Deployment Steps -

Follow these steps to upload and create the CloudFormation stack using the AWS Management Console:

  1. Sign in to the AWS Management Console: Log in to your AWS account if you haven’t already.

2. Navigate to CloudFormation: Go to the AWS CloudFormation service from the AWS Management Console.

3. Click the “Create stack” button.

4. Upload the CloudFormation template file (YAML).

Yaml file :

AWSTemplateFormatVersion: '2010-09-09'
Description: "AWS CloudFormation Template for the EKS Cluster."
Parameters:
  EnvironmentName:
    Description: Environment name for the application
  EKSClusterName:
    Type: String
    Description: The Desired name of your AWS EKS Cluster.
  NetworkStackName:
    Description: Name of an active CloudFormation stack of networking resources
    Type: String
    MinLength: 1
    MaxLength: 255
    AllowedPattern: "^[a-zA-Z][-a-zA-Z0-9]*$"
  EFSPort:
    Description: EFS port
    Default: '2049'
    Type: Number
  GRPCPort:
    Description: GRPC port
    Default: '7233'
    Type: Number
  AvailabilityZoneName:
    Description: AvailabilityZone for EFS Filesystem
    Default: ca-central-1a
    Type: String
Resources:
  EKSIAMRole:
    Type: 'AWS::IAM::Role'
    Properties:
      RoleName: !Sub '${EnvironmentName}-${EKSClusterName}-iamrole'
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          - Effect: Allow
            Principal:
              Service:
              - eks.amazonaws.com
            Action:
            - 'sts:AssumeRole'
      ManagedPolicyArns:
        - arn:aws:iam::aws:policy/AmazonEKSClusterPolicy
        - arn:aws:iam::aws:policy/AmazonEKSServicePolicy
        - arn:aws:iam::aws:policy/AmazonEKSVPCResourceController
  EKSpodexecutionRole:
    Type: 'AWS::IAM::Role'
    Properties:
      RoleName: !Sub '${EnvironmentName}-${EKSClusterName}-podexecrole'
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          - Effect: Allow
            Principal:
              Service:
              - eks-pods.amazonaws.com
            Action:
            - 'sts:AssumeRole'
  EKSpodexecutionPolicy:
    Type: 'AWS::IAM::Policy'
    Properties:
      PolicyName: !Sub '${EnvironmentName}-${EKSClusterName}-podexecpolicy'
      PolicyDocument:
        Version: 2012-10-17
        Statement:
        - Effect: Allow
          Action:
            - 'ecr:GetAuthorizationToken'
            - 'ecr:BatchCheckLayerAvailability'
            - 'ecr:GetDownloadUrlForLayer'
            - 'ecr:BatchGetImage'
            - 'logs:CreateLogStream'
            - 'logs:CreateLogGroup'
            - 'logs:DescribeLogStreams'
            - 'logs:PutLogEvents'
          Resource: '*'
      Roles:
        - !Ref EKSpodexecutionRole
  ControlPlaneSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Cluster communication with worker nodes
      VpcId:
        !ImportValue
          'Fn::Sub': '${NetworkStackName}-VpcId'
  PodSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for Temporal Pods
      VpcId:
        !ImportValue
          'Fn::Sub': '${NetworkStackName}-VpcId'
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: !Ref GRPCPort
          ToPort: !Ref GRPCPort
          CidrIp:
             Fn::ImportValue: !Sub ${NetworkStackName}-PrivateSubnet1Cidr
          Description: !Sub Inbound from Private Subnet1 to ${EnvironmentName} GRPC Port
        - IpProtocol: tcp
          FromPort: !Ref GRPCPort
          ToPort: !Ref GRPCPort
          CidrIp:
             Fn::ImportValue: !Sub ${NetworkStackName}-PrivateSubnet2Cidr
          Description: !Sub Inbound from Private Subnet2 to ${EnvironmentName} GRPC Port
  EKSCluster:
    Type: AWS::EKS::Cluster
    Properties:
      Name: !Sub '${EnvironmentName}-${EKSClusterName}'
      RoleArn:
        "Fn::GetAtt": ["EKSIAMRole", "Arn"]
      ResourcesVpcConfig:
          SecurityGroupIds:
          - !Ref ControlPlaneSecurityGroup
          SubnetIds:
          - !ImportValue
            'Fn::Sub': '${NetworkStackName}-PrivateSubnet1Id'
          - !ImportValue
            'Fn::Sub': '${NetworkStackName}-PrivateSubnet2Id'
      Version: '1.26'
  EKSProfiles:
    Type: AWS::EKS::Profile
    Properties:
      ClusterName: !Sub '${EnvironmentName}-${EKSClusterName}'
      ProfileName: !Sub '${EnvironmentName}-EKS-Profiles'
      PodExecutionRoleArn: !GetAtt
        - EKSpodexecutionRole
        - Arn
      Selectors:
        - Namespace: default
        - Namespace: kube-system
        - Namespace: temporal
        - Namespace: external-secrets
      Subnets:
        - !ImportValue
          'Fn::Sub': '${NetworkStackName}-PrivateSubnet1Id'
        - !ImportValue
          'Fn::Sub': '${NetworkStackName}-PrivateSubnet1Id'
    DependsOn: EKSCluster
  EFSSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: !Sub Security group for Elastic Search cluster of ${EnvironmentName} environment
      GroupName: !Sub '${EnvironmentName}-GroupNameEFS
      VpcId:
        Fn::ImportValue: !Sub ${NetworkStackName}-VpcId
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: !Ref EFSPort
          ToPort: !Ref EFSPort
          CidrIp:
             Fn::ImportValue: !Sub ${NetworkStackName}-PrivateSubnet1Cidr
          Description: !Sub Inbound from Private Subnet1 to ${EnvironmentName} efs filesystem mount
        - IpProtocol: tcp
          FromPort: !Ref EFSPort
          ToPort: !Ref EFSPort
          CidrIp:
             Fn::ImportValue: !Sub ${NetworkStackName}-PrivateSubnet2Cidr
          Description: !Sub Inbound from Private Subnet2 to ${EnvironmentName} efs filesystem mount
Outputs:
  EKSClusterEndpoint:
    Description: 'EKS OIDC Connection URL'
    Value:
      "Fn::GetAtt": ["EKSCluster", "OpenIdConnectIssuerUrl"]
    Export:
      Name: !Sub "${AWS::StackName}-EKSClusterEndpoint"
  PodSecurityGroup:
    Description: 'EKS Pod Security group'
    Value:
      Ref: PodSecurityGroup
    Export:
      Name: !Sub "${AWS::StackName}-PodSecurityGroup"

5. Specify Stack Details:

  • Enter a Stack name for your deployment.

  • Provide parameter values as needed.

  • Review and acknowledge the capabilities .

  • You can set additional stack options or tags if necessary.

6. Review and Create:

  • Review the stack details and configuration.

  • Click “Create stack” to initiate the deployment.

7. Monitor Stack Creation:

  • The CloudFormation stack creation process will begin.

  • Monitor the stack events in the AWS Management Console.

Summary :-

This AWS CloudFormation template serves as a blueprint for setting up an EKS cluster, enhancing operational efficiency and scalability for containerized applications.This template ensures that your EKS cluster is established in a secure and well-structured manner, allowing you to focus on deploying and managing containerized workloads without the hassle of manual setup and configuration. It’s a valuable resource for orchestrating robust and scalable Kubernetes-based applications in the AWS cloud environment.
