Apache Spark is a tool used to process large amounts of data. It’s fast, scalable, and great for big data tasks. However, sometimes when working with Spark, you might run into a common issue: the "Executor Out of Memory" error. If you've seen this error, you might wonder, "Why does this happen?" In this post, we'll explain the causes of this error in simple terms and show you how to avoid it, with examples to make it easy to understand.

Image By Author

What is an Executor in Spark?

To understand why the error happens, you first need to know what an executor is in Apache Spark.

• Executor: It’s a small worker process that runs on a computer in your cluster (a group of computers working together). Each executor is responsible for running tasks (small pieces of work) and uses memory to process the data.

When you run a job in Spark, the work is split into tasks, and those tasks are sent to different executors to be processed. If one of these executors doesn’t have enough memory to complete its task, you get the "Executor Out of Memory" error.

Why Does the "Executor Out of Memory" Error Occur?

There are several reasons why this error happens. Let's go over the most common ones:

1. Not Enough Memory for Executors

• Each executor is given a set amount of memory when your Spark job starts. If the amount of data or the operations you're performing need more memory than what's been given, the executor will run out of memory.

2. Shuffling Large Amounts of Data

• When Spark needs to move data around between different parts of your program, it's called shuffling. For example, when you use operations like groupByKey or join, Spark might shuffle data between executors. If the data being shuffled is large, it can take up a lot of memory, causing the executor to run out of memory.

3. Handling Large Datasets in a Single Partition

• Sometimes, a single chunk (or partition) of your data may become too big. If one partition becomes too large, the executor trying to process that partition might not have enough memory to handle it.

4. Memory Leaks in Code

• Sometimes, code or libraries you’re using may hold on to memory they no longer need. This is called a memory leak. Over time, this can eat up all the available memory, causing the executor to crash.

Example: How This Error Happens

Let's look at an example that demonstrates how an "Executor Out of Memory" error might occur. We'll use some simple Spark code to generate a large dataset and perform a memory-heavy operation.

Step 1: Set Up Spark with Limited Memory

• First, we need to set up Spark. For this example, let’s say we’re giving each executor just 1 GB of memory, which isn’t much for big data.

from pyspark.sql import SparkSession

# Start a Spark session with 1 GB of memory for each executor
spark = SparkSession.builder \
    .appName("Executor Out of Memory Example") \
    .config("spark.executor.memory", "1g") \
    .getOrCreate()

Step 2: Create a Large Dataset

• Now, we’ll create a large dataset with 10 million rows. This is just sample data for our example.

# Create a DataFrame with 10 million rows
data = [(i, i * 2) for i in range(10000000)]  # 10 million rows
df = spark.createDataFrame(data, ["id", "value"])
df.printSchema()  # Check the structure of the DataFrame

Step 3: Run a Memory-Heavy Operation

• Let’s now run a groupBy operation. This will require Spark to shuffle data between executors, which can easily lead to memory issues if the data is large.

# Perform a groupBy operation, which triggers data shuffling
grouped_df = df.groupBy("id").count()
grouped_df.show()  # Try to show the result (this might cause a memory error)

Step 4: See the Error

• When you run the code above, you might see an error like this:

ExecutorLostFailure (executor 1 exited caused by one of the running tasks) Reason: Executor heartbeat timed out

• This means one of the executors ran out of memory while processing the task, leading to the "Out of Memory" error.

How to Fix the "Executor Out of Memory" Error

There are several ways to fix this problem. Here are some strategies you can use:

1. Increase the Memory for Executors

• If your executors are running out of memory, the simplest solution is to give them more memory. You can do this by changing the configuration when you start your Spark session.

spark = SparkSession.builder \
    .appName("Executor Memory Fix") \
    .config("spark.executor.memory", "4g") \  # Increase memory to 4 GB
    .getOrCreate()

2. Increase the Number of Partitions

• If a partition of your data is too big, you can break the data into more partitions so each executor gets a smaller chunk. This can help balance the memory usage.

df = df.repartition(100)  # Split the data into 100 partitions

3. Optimize Your Operations

• Some operations, like groupByKey, can cause large shuffles. If possible, try using more efficient operations like reduceByKey to minimize the amount of data being shuffled.

# Use reduceByKey instead of groupByKey for better memory usage
rdd = df.rdd.map(lambda x: (x[0], x[1]))
reduced_rdd = rdd.reduceByKey(lambda a, b: a + b)

4. Be Careful with Caching

• When you cache data in Spark, it stays in memory for future use. If you cache too much data, it might take up all your memory. Only cache data when you really need to, and remember to uncache it when you’re done.

df.cache()  # Cache the DataFrame in memory
# Perform operations...
df.unpersist()  # Uncache it when done

Conclusion

The "Executor Out of Memory" error in Spark happens when the memory needed to process data is more than the memory available for an executor. This can happen because of insufficient memory, large data shuffles, improper partitioning, or memory leaks in your code.

To avoid this error:

• Increase the memory for your executors.

• Split your data into more partitions.

• Optimize operations that involve data shuffling.

• Cache data wisely and uncache when done.

By following these tips, you’ll be able to handle memory better in your Spark applications and prevent the "Executor Out of Memory" error from happening.

Sample Output After Fixing the Issue:

• After increasing memory or optimizing the code, the output could look something like this:

+---+-----+
| id|count|
+---+-----+
|  1|    1|
|  2|    1|
|  3|    1|
...
|9999999| 1|
+---+-----+

• This shows that the operation completed successfully, and you avoided the memory issue.

I hope this explanation helps you understand why the "Executor Out of Memory" error happens in Spark and how to fix it!
